High Wear Resistance Composite Steel Plates

Quantity:
Availability:





Inquire Add to Basket

Type:
Steel Plate
Standard:
ASTM, AISI, GB, JIS, DIN, BS
Certification:
ISO
Surface Treatment:
Coated
Technique:
Hot Rolled
Special Use:
Wear Resistant Steel

Product Description

Specifications

Standard: AISI, ASTM, BS, DIN, GB, JIS, AISI, ASTM, BS, DIN, GB, JIS, AISI, ASTM, BS, DIN, GB, JIS
Grade: AR400/500/600/700,Weldox 420/460/500/700/800/900, first-class
Thickness: 8-200mm, 8-200mm
Place of Origin: China (Mainland)
Brand Name: high wear resistance composite steel plates
Model Number: high wear resistance composite steel plates
Type: Steel Plate
Technique: Hot Rolled
Surface Treatment: HIC, SSC, SPWHT
Application: railway vehicles, bridges, towers and other steel structures, railway
Special Use: Wear Resistant Steel
Width: 1500-4200mm, 1500-4200mm
Length: as customer required, as customer required
Description: high wear resistance composite steel plates
Heat Treament: Quenched, Normalized, Tempering, Q+T
Terms: Ex-Work,FOB,CNF,CFR,CIF,etc
Certificate: ISO9001:2000
Port: China

Packaging & Delivery

Packaging Details:Properly packed for ocean freight exportation in containers
1. Bundle
2. Water-proof Draft Paper
3. Galvanized Steel Sheet
Delivery Detail:15~20days after receiving deposit

High Wear Resistance Composite Steel Plates

high wear resistance composite steel plates
Specifications
1.Grade:WNM360 NM360 WNM450 NM450 JFE-EH450A 450V WNM500 NM450 JFE-EH500A 500V K500 NM500

2.Thickness:8-200mm

3.Width:1500-4200mm

4.Length:3000-12000mm or as customer required

5.Application: railway vehicles, bridges, towers and other steel structures, railway

6.technique:Quenched, Normalized, Tempering, Q+T

7.Standard :AISI, ASTM, BS, DIN, GB, JIS, AISI, ASTM, BS, DIN, GB, JIS

8.Chemical Element

rade	Chemical composition
rade	C	Si	Mn	P	S	Cr	Ni	Mo	B
NM360	0.25	0.7	1.6	0.025	0.015	0.8	0.5	0.5	0.0008-0.003
NM400	0.3	0.7	1.6	0.025	0.01	1	0.7	0.5	0.0008-0.003
NM450	0.35	0.7	1.7	0.02	0.01	1.1	0.8	0.55	0.0008-0.003
NM500	0.38	0.7	1.7	0.02	0.01	1.2	1	0.65	0.0008-0.003
NM600	0.45	0.7	1.9	0.02	0.01	1.5	1	0.8	0.0008-0.003
