High Quality Boiler and Pressure Vessel Steel Plate

Quantity:
Availability:





Inquire Add to Basket

Type:
Steel Plate
Standard:
ASTM, AISI, GB, JIS, DIN, BS
Certification:
ISO, RoHS, IBR
Surface Treatment:
Coated
Technique:
Hot Rolled
Special Use:
High-strength Steel Plate

Product Description

Our company special in Steel Product, Steel Plate, carbon steel plate, hot rolled steel plate, cold rolled steel plate, stainless steel plates, steel circle, color coated steel plate, hot plate, steel coils, etc.

High Quality Boiler and Pressure Vessel Steel Plate

Boiler and pressure vessel plate 410B
Applications: Widely used in petroleum, chemical, power plants, boilers and other industries for the production of reactors, heat exchangers, separators, tank, gas cans, liquid gas storage tank, pressure vessel, boiler drum, liquefied petroleum gas cylinders, high-pressure water station, scroll wheel and other equipment and components.

Specifications

Standard: AISI, ASTM, BS, DIN, GB, JIS
Grade: Boiler and pressure vessel steel plateAISI4140,SA285GrC,SB410,410B,
Thickness: 6~300mm
Place of Origin: Henan, China (Mainland)
Model Number: AISI4140,SA285GrC,SB410,410B,KP42,Q245R,Q345R,16MnDR,SPV355,Q370R,
Type: Steel Plate
Technique: Hot Rolled
Surface Treatment: no-coated
Application: bolier plate and container plate
Special Use: High-strength Steel Plate
Width: 1500~4000mm
Length: 5000~18000mm
SA285GrC: Boiler and pressure vessel steel plate
SB410: Competitive price Boiler and pressure vessel steel plate
SPV355: High Quality Boiler and pressure vessel steel plate
S)A515Gr60: Boiler and pressure vessel steel plate+N

Packaging & Delivery

Packaging Details:as required
Delivery Detail:around 30 days

Specifications

Boiler and pressure vessel steel plate
Standard :JIS ASTM DIN EN GB
Tickness:6-300mm
Width:1500-4200mm
length:3000-18000mm

Boiler and Pressure vessel steel plate

Grade	Standared
AISI4140	WJX039-2005
SA285GrC	ASME
SB410	JISG3103
410B	CCS
KP42	WYJ
Q245R	GB713
Q345R	GB713
16MnDR	GB3531
SPV355	JISG3115
Q370R	GB713
(S)A515Gr60	ASME(ASTM)
(S)A515Gr70	ASME(ASTM)
(S)A516Gr60	ASME(ASTM)
(S)A516Gr70	ASME(ASTM)
P235GH	EN10028
HII/P265GH	EN10028
P295GH	EN10028
P355GH	EN10028
P355NH	EN10028
P355NL1	EN10028
19Mn6	DIN17155
15Mo3	DIN17155
16Mo3	EN10028
A537CL1	ASTM
09MnNiDR	GB3531
SA662GrC	ASTM(ASME)
18MnMoNbR	GB713
15MnNiDR	GB3531
A48CPR	WYJ002-2005
(S)A515Gr65	ASME(ASTM)
(S)A516Gr65	ASME(ASTM)
SA612M	WYJ
SA537CL2	ASTM
SB450	JISG3103
SA387GR11	ASTM
SA387GR11CL2	ASTM
SA387GR11CL1	ASTM
SA387GR12	ASTM
SA387GR22	ASTM
13CrMo4-5	EN10028
10CrMo9-10	EN10028
13CrMo44	DIN17155
10CrMo910	DIN17155
1.25Cr0.5MoSi	ASTM

Thickness:6~300mm

Width:1500~4200mm

Length:3000~18000mm

Services: Pretreatment (derusting, lacquering, Painting, Sand dusting) test (UT, HIC, Impact test, PWHT, Z15, Z25, Z35 etc) Cutting, Welding, Painting, Flaw-Detection (Grade1, Grade2).

Process: EAF+LF+VD+Forged+Heat Treatment (optional).

components	C	Si	Mn	P	S	Ti	TAl	V
				≤	≤
	0.13-0.18	0.20-0.30	0.50-0.85	0.02	0.018	0.015-0.030	0.020-0.040
Use	Widely used in petroleum, chemical, power plants, boilers and other industries for the production of reactors, heat exchangers, separators, tank, gas cans, liquid gas storage tank, boiler drum, liquefied petroleum gas cylinders, high-pressure water station, scroll wheel and other equipment and components.
size	3000-18800mm1500-4020mm6-700mm
Thickness	6-700mm
Standard	CCS
Material	410B
Packing	According to the demand of the customer inquire
Surface treatment	Hot-rolled
Delivery time	According to the quantity; asap, average period in 30 days.
