A572gr50 Standard Sizes S355 Steel Plate

Quantity:
Availability:





Inquire Add to Basket

Type:
Steel Plate
Standard:
ASTM, AISI, JIS
Certification:
ISO, RoHS, IBR
Surface Treatment:
Coated
Technique:
Hot Rolled
Application:
Ship Plate, Boiler Plate, Container Plate

Product Description

Low-Alloy / High-Strength Steel A572Gr50

Specifications
Standard:AISI, ASTM, DIN, GB, JIS
Grade:A572Gr50
Thickness:16mm-25mm
Model Number:A572Gr50
Type:Steel Plate
Technique:Hot Rolled
Surface Treatment:Coated
Application:Ship Plate
Special Use:High-strength Steel Plate
Width:1500mm-4300mm
Length:6000mm-18000mm
steel price plate:s355 steel plate 50mm thick
Product Name:25mm thick steel plate hot rolled
Material:s355 steel plate 50mm thick
hot rolled hot rolled steel plate:s355 steel plate 50mm thick
hot rolled steel plate steel plate:steel plate price s355 steel plate 50mm thick
alloy steel plate price per:16mm thick steel plate
A572gr50 alloy steel plate price per kg:various thickness steel plate
quality alloy steel plate price per kg:16mm thick steel plate
standard steel plate sizes:a572 steel plate standard sizes
hot rolled steel plate low price:alloy steel plate price per kg
Packaging & Delivery
Packaging Details:
1. by bundles for thickness under thickness under 10mm 2. piece by piece for thickness over 10mm 3. for steel plates cut to piece by wood pallet to customer requirements
Delivery Detail:15 days for stock sizes and 35 days for new production sizes
Production Description

Standard	Grade	C max	Mn max	Si max	P	S	Yield strength max	Tensile strength	Elongation%
ASTM A572M	50	0.23	1.35	0.55	0.04	0.05	345	450	21
ASTM A572M	65	0.25	1.35	0.55	0.04	0.05	450	550	17

1. Material : A572 GR50 Hot rolled low alloy steel sheet and structural plate cut to size
2. Thickness: 1mm-800mm,
3. Width: 100mm-3500mm
4. Length: in sheets: 100mm-13700mm
5. Heat treatment: normalized or tempered
6. Cut to order and cut to size, any size is available
(We also can produce according to customer's requirement)
A572gr50 Standard Sizes S355 Steel Plate

Steel Plate Materials Can Be Supplied

COMMODITY NAME	GRADES	STANDARD	Application
Boiler and Pressure Vessel Steel Plates	Q245R,Q345R,Q370R,15CrMoR,18MnMoNbR,13MnNiMoR, 12Cr1MoVR,12Cr2Mo1R,14CrMoR,	GB713	Widely used in petroleum, chemical industry, power station, boiler, etc, used to make the reactor, heat exchanger, separator, spherical tank, liquid tank, nuclear reactor pressure vessel, boiler drum, liquefied petroleum gas cylinders, high-pressure hose, hydraulic spiral case, such as hydropower station equipment and components.
	16MnDR,09MnNiDR,15MnNiDR	GB3531
	07MnCrMoVR,07MnNiCrMoVDR/12MnNiVR	QB/GB
	SB410,SB450,SB480	JIS G3103
	SPV235,SPV315,SPV355,SPV410,SPV490	JIS G3115
	SGV41O,SGV450,SGV480	JIS G3118
	SBV1A,SBV1B,SBV2,SBV3	JIS G3119
	SEV245,SEV295,SEV345	JIS G3124
	HI,HII,10CrMo910,15Mo3,13CrMo44,19Mn6	JDIN17155
	BHW35/13MnNiMo54	MILL STANDARD
	1Cr0.5Mo,2.25Cr1Mo,1.25Cr0.5Mo,Q245R\|Q345R(HIC)/(R-HIC)	MILL STANDARD
	(s)A229M, (s)A515M(Gr.A,B,C), (s)A387M(GR11,12,22), (s)A537M(GL1,GL2), (s)A662M(GrA,B,C), (s)A302M(GraA,B,C,D), (s)A737M(Gr.B,C), (s)A738M(Gr.A,B,C), (s)A533M, (s)A285Gr:A,B,C,D	ASTM ASME
	P235GH,P265GH,P395GH,P355GH,16Mo3	EN10028-2
	A42,A52,A48	NFA36-205
	20MnHR,Q245HR,Q345HR,KP42,AISI4140,A48CPR,SA612M	MILL STANDARD
	161G430	BS1501
	WDB620/Q500FC	MILL
Low Alloy High Strength Steel Plate	12Mn,15MnVN,16Mn,15MnV,14MnNb	GB1591	Widely used in manufacturing plant, general construction and all kinds of engineering machinery, such as mining and all kinds of engineering construction in the drill, excavator, electric wheel skip, mine car, excavators, loaders, bulldozers, cranes, mining hydraulic support and other mechanical equipment and structures.
	Q295(A,B),Q345(A,B,C,D,E)Q390(A,B,C,D,E), Q420(A,B,C,D,E),Q460(C,D,E)	GB/T1591
	Q500(D,E),Q550(D,E),Q620(D,E),Q690(D,E)	GB/T16270
	SM490(A,B,C),SM490Y(A,B),SM520(B,C),SM570	JIS G 3106
	St44-3,St52-3,St50-2, St60-2,St70-2	DIN 17100
	StE315,StE355,StE380,STe420,StE460,StE500	DIN 17102
	A572M(Gr42.50,60,65),A633M9(A,B,C,D,E)	ASTM
	S275(JR,JO,J2G3,J2G4),S355(JR,JO,J2G3,J2G4,E395,E355,E360)
	S275N,S275NL,S355N,S355NL,S420N,S420NL,S460N,S460NL	EN10025
	50(A,B,C,D,DD,EE,F),43(A,B,C,D,EE),55(C,EE,F)	EN10113
	Fe430(A,B,C,D),Fe510(B,C,D)	BS4360
	WH60,WH410LK(BB41BF),WH490LK(BB503),Q550CFC	IOS630
	WDB690,WDB780,WH70,WH80 IE0650,IE1006,SHT60
Corrision Resistance Steel Plate	08Cu,16MnCu,Q245R\|Q345R(HIC)\(R-HIC)		Significantly improve the corrosion resistance of structure, prolong the service life of structure, can be used to produce in the atmospheric environment and work under corrosive gases, liquids of structure.
	St37-3Cu3	DIN17100
	A588M(A,B,C,K),A242MCL.2	ASTM
	Cor-TenB,10CrMoAL
	16CuCr,12MnCuCr,15MnCuCr-QT,09CuPCrNi	GB 4172/4171
	SMA400(AW,BW,CW),SMA400(AP,BP,CP),SMA490(AW,BW,CW) SMA490(AP,BP,CP),SMA570W,SMA570P	JIS G3114
	Fe235W,Fe355W,WR50B,WR50C	IOS 4952/BS4360
	A709M(Gr36,50,50W,70W)	ASTM
Construction, Structural Steel Plate	Q235GJ,Q345GJC.D-Z35,Q390GJ,Q460GJC	GB/T19879	Used to make industrial and civil buildings such as the pillar and bearing beam, which is suitable for high-rise buildings and large span buildings.
	SN400(A,B,C),SN490(B,C)	JIS G 3136
	275(D,E,EZ),355(D,E,EM),450(EM,EMZ)	Bs7179
Alloy Structure Steel Plate	15CrMo,20CrMo,30CrMo,35CrMo,20Cr, 40Cr,20Mn2,40Mn2,20CrMnMo,12Cr1MoV,20MnSi 30CrMnSiA,12CrMoVNi(RQ65),50Mn2V,42CrMo	MILL STANDARD	various kinds of alloy structure and its components, such as boiler super heater container, large diameter tube structure.
	25CrMo4,34CrMo4,42CrMo4	EN10083-1
	S45C-S55C	JIS G450
	45-55,50Mn,SM45-SM55,SM3Cr2Mo,SM3Cr2Mo,SM3Cr2Ni1Mo	GB711/YB/T107
	NM360,NM400	MILL
Carbon Structure Steel Plate	Q235-Q275	GB3272	make all types of steel rivet, bolts, and welding structure.
	10-55,20Mn-50Mn	GB711/
	SS400/SM400(A,B)	JISG3103 /G3106
	S10C-S55C	JIS G4051
	St37-2,St37-3	DIN17100
	A36,A283(A,B,C,D),1010-1050	ASTM
	40(A,B,C,D,E)	BS4306
	S235(JR ,JO ,J2G3,J2G4)	EN10025
	1C22,1C25,1C30,1C35,1C40,1C45,1C50,1C55	EN10083-2
	Fe360(A,B,C,D)	ISP630
	D40,E40	GB5313
	AP1 SPEC 2H Gr42,Gr50	API

A572gr50 Standard Sizes S355 Steel Plate
About Productions

Processing technique	1. Heat treatment facilities for hot-rolled, controlled rolling, normalizing, 2. Annealing, tempering, quenching, normalizing plus tempering, quenching and tempering, 3. Other delivery states are available as customer's requirement.
Feature of hot rolled steel plate	1. Heat conduction 2. Excellent freezing, even structure with pressure resistance 3. Good mechanical properties
Excellent performances hot-rolled steel products	1. High strength, good toughness, 2. Easy for molding process and good weldability,
Main application	1. Automobile, Bridges, Buildings, 2. Machinery, Pressure vessel industries. 3. Ship building, Engineering construction, 4. Mechanical manufacturing, Pavement slab, ect.
